Datasets


The flooder package includes a curated collection of point cloud datasets, including variations of classical ones as well as new ones, designed to be geometrically challinging and to test topological ML methods. The package allows to import and use the datasets with only few lines of code:

from flooder.datasets import (
    CoralDataset, MCBDataset, RocksDataset,
    ModelNet10Dataset, SwisscheeseDataset, LargePointCloudDataset,
)

dataset = CoralDataset('./coral_dataset/')
for data in dataset:
    print(data.x.shape, data.y)

In particular, we provide the following datasets:

  • CoralDataset: this dataset consists of 81 point clouds, each comprising 1 million points uniformly sampled from surface meshes of coral specimens provided by the Smithsonian 3D Digitization program (https://3d.si.edu/corals). Labels correspond to the coral's genus, with 31 Acroporidae samples (label 0) and 52 Poritidae samples (label 1). Due to its small size, it is challenging for geometric neural networks, while topology-based methods are often at an advantage.
  • RocksDataset: this synthetic dataset consists of 1000 point clouds representing symulated rock samples from two classes. The voxel grids are produced by the PoreSpy library (https://porespy.org/) with classes corresponding to the generation method, fractal noise and blobs, each with 500 samples. It offers also a regression task for the estimation of the surface of the material.
  • ModelNet10Dataset: this dataset consists of 4899 point clouds, each comprising 250k points uniformly sampled from surface meshes from the ModelNet10 dataset (Wu et al., 3D ShapeNets: A Deep Representation for Volumetric Shapes, CVPR 2015). This dataset contains topologically simple objects, and since it is a high-resolution version of a well-studied dataset, it is useful to compare methods with the existing literature.
  • MCBDataset: this dataset consists of 1745 point clouds, each comprising 1 million points uniformly sampled from surface meshes from a subset of the MCB dataset (Kim et al., A large-scale annotated mechanical components benchmark for classification and retrieval tasks with deep neural networks, ECCV, 2020), where we only retain geometrically complex objects. Therefore, it is useful to probe the capabilities of topological ML methods.
  • SwisscheeseDataset: this dataset class allows to procedurally generate a dataset of point clouds with multiple spherical voids. In particular, each sample consists of points uniformly sampled from a 3D axis-aligned box with multiple spherical voids removed ("Swiss cheese"). The number of voids defines the class label.
  • LargePointCloudDataset: this dataset contains two point clouds (a virus and a coral) with more than 10M points each. It can be used to benchmark the speed and memory usage of geometric algorithms (e.g. simplicial complex constructions) on real-world data. The EMD-50844 point cloud is obtained from the protein structure of the RV-A89 virus, available at www.ebi.ac.uk/emdb/EMD-50844. The Leptoseris paschalensis point cloud comprises the vertices of the mesh of the USNM 53156 coral obtained from the Smithsonian 3D Digitization initiative.
